BRT22M Vishay PHOTOCOUPLER TRIAC
BRT22M Images
BRT22M Images
BRT22M
  • Manufacturer: Vishay
  • Category: Isolators~Optoisolators - Triac, SCR Output Package/Case: 6-DIP (0.300, 7.62mm)
  • Description: PHOTOCOUPLER TRIAC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
BRT22M Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
BRT22M Specifications:
  • MfrPart.: BRT22M
  • Mfr: Vishay Semiconductor Opto Division
  • Description: PHOTOCOUPLER TRIAC
  • Product Category: Isolators~Optoisolators - Triac, SCR Output
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • OutputType: Triac
  • ZeroCrossingCircuit: Yes
  • NumberofChannels: 1
  • Voltage-Isolation: 5300Vrms
  • Voltage-OffState: 600 V
  • StaticdV/dt(Min): 10kV/µs
  • Current-LEDTrigger(Ift)(Max): 3mA
  • Current-OnState(It(RMS))(Max): 300 mA
  • Current-Hold(Ih): 500µA
  • TurnOnTime: 35µs
  • Voltage-Forward(Vf)(Typ): 1.16V
  • Current-DCForward(If)(Max): 60 mA
  • OperatingTemperature: -40°C ~ 100°C
  • MountingType: Through Hole
  • Package/Case: 6-DIP (0.300, 7.62mm)
  • BRT22M Vishay, PHOTOCOUPLER TRIAC, Isolators~Optoisolators - Triac, SCR Output
