DG212BDJ Images
- Manufacturer: Vishay
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: IC SWITCH QUAD SPST 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG212BDJ Specifications:
- MfrPart.: DG212BDJ
- Mfr: Vishay Siliconix
- Description: IC SWITCH QUAD SPST 16DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 85Ohm
- Channel-to-ChannelMatching(ΔRon): 2Ohm
- Voltage-SupplySingle(V+): 4.5V ~ 25V
- Voltage-SupplyDual(V±): ±4.5V ~ 22V
- SwitchTime(TonToff)(Max): 300ns, 200ns
- -3dbBandwidth: -
- ChargeInjection: 1pC
- ChannelCapacitance(CS(off)CD(off)): 5pF, 5pF
- Current-Leakage(IS(off))(Max): 500pA
- Crosstalk: -95dB @ 100kHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- DG212BDJ Vishay, IC SWITCH QUAD SPST 16DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG212BDJ, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
