DG613DY Images
- Manufacturer: Vishay
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SOIC (0.154, 3.90mm Width)
- Description: IC SWITCH QUAD NO/NC 16-SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG613DY Specifications:
- MfrPart.: DG613DY
- Mfr: Vishay Siliconix
- Description: IC SWITCH QUAD NO/NC 16-SOIC
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: DPDT
- Multiplexer/DemultiplexerCircuit: 2:2
- NumberofCircuits: 1
- On-StateResistance(Max): 45Ohm
- Channel-to-ChannelMatching(ΔRon): 2Ohm
- Voltage-SupplySingle(V+): 10V ~ 18V
- Voltage-SupplyDual(V±): ±10V ~ 15V
- SwitchTime(TonToff)(Max): 35ns, 25ns
- -3dbBandwidth: 500MHz
- ChargeInjection: 4pC
- ChannelCapacitance(CS(off)CD(off)): 3pF, 2pF
- Current-Leakage(IS(off))(Max): 250pA
- Crosstalk: -87dB @ 10MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.154, 3.90mm Width)
- DG613DY Vishay, IC SWITCH QUAD NO/NC 16-SOIC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG613DY, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
