IRC530PBF Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220-5
- Description: MOSFET N-CH 100V 14A TO220-5
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRC530PBF Specifications:
- MfrPart.: IRC530PBF
- Mfr: Vishay Siliconix
- Description: MOSFET N-CH 100V 14A TO220-5
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 14A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 160mOhm @ 8.4A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 26 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 700 pF @ 25 V
- FETFeature: Current Sensing
- PowerDissipation(Max): 88W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220-5
- IRC530PBF Vishay, MOSFET N-CH 100V 14A TO220-5, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
