IRF820L Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I2PAK
- Description: MOSFET N-CH 500V 2.5A I2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRF820L Specifications:
- MfrPart.: IRF820L
- Mfr: Vishay Siliconix
- Description: MOSFET N-CH 500V 2.5A I2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 2.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 3Ohm @ 1.5A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 24 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 360 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3.1W (Ta), 50W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I2PAK
- IRF820L Vishay, MOSFET N-CH 500V 2.5A I2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRF820L, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
