IRFP22N60K Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247AC
- Description: MOSFET N-CH 600V 22A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRFP22N60K Specifications:
- MfrPart.: IRFP22N60K
- Mfr: Vishay Siliconix
- Description: MOSFET N-CH 600V 22A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 22A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 280mOhm @ 13A, 10V
- Vgs(th)(Max)@Id: 5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 150 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 3570 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 370W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247AC
- IRFP22N60K Vishay, MOSFET N-CH 600V 22A TO247-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
