IRL520STRR Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK
- Description: MOSFET N-CH 100V 9.2A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRL520STRR Specifications:
- MfrPart.: IRL520STRR
- Mfr: Vishay Siliconix
- Description: MOSFET N-CH 100V 9.2A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 9.2A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4V, 5V
- RdsOn(Max)@IdVgs: 270mOhm @ 5.5A, 5V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 12 nC @ 5 V
- Vgs(Max): ±10V
- InputCapacitance(Ciss)(Max)@Vds: 490 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3.7W (Ta), 60W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D2PAK
- IRL520STRR Vishay, MOSFET N-CH 100V 9.2A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
