IRLBA3803 Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SUPER-220™ (TO-273AA)
- Description: MOSFET N-CH 30V 179A SUPER-220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRLBA3803 Specifications:
- MfrPart.: IRLBA3803
- Mfr: Vishay Siliconix
- Description: MOSFET N-CH 30V 179A SUPER-220
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Discontinued at
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 179A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 5mOhm @ 71A, 10V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 140 nC @ 4.5 V
- Vgs(Max): ±16V
- InputCapacitance(Ciss)(Max)@Vds: 5000 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 270W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: SUPER-220™ (TO-273AA)
- IRLBA3803 Vishay, MOSFET N-CH 30V 179A SUPER-220, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRLBA3803, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
