TCMD4000 Images
- Manufacturer: Vishay
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 16-SOIC (0.173, 4.40mm Width)
- Description: OPTOISO 3.75KV 4CH DARLNG 16-SOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TCMD4000 Specifications:
- MfrPart.: TCMD4000
- Mfr: Vishay Semiconductor Opto Division
- Description: OPTOISO 3.75KV 4CH DARLNG 16-SOP
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- NumberofChannels: 4
- Voltage-Isolation: 3750Vrms
- CurrentTransferRatio(Min): 600% @ 1mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): -, 250µs
- Rise/FallTime(Typ): 300µs, -
- InputType: DC
- OutputType: Darlington
- Voltage-Output(Max): 35V
- Current-Output/Channel: 80mA
- Voltage-Forward(Vf)(Typ): 1.25V
- Current-DCForward(If)(Max): 60 mA
- VceSaturation(Max): 1V
- OperatingTemperature: -40°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.173, 4.40mm Width)
- TCMD4000 Vishay, OPTOISO 3.75KV 4CH DARLNG 16-SOP, Isolators~Optoisolators - Transistor, Photovoltaic Output
